MULTIFUNCTIONAL MACHINE – TURBOLOADER H440

The Turboloader is a versatile, versatile, powerful, safe machine with an environmentally friendly engine that complies with EU directives. It is ideal for gardening, public grounds maintenance, agriculture, construction work and any other industrial tasks where power and functionality are the main goal.

CHASSIS

The articulated chassis gives a very tight turning radius, :reducing the room needed for manoeuvring and enabling Turboloader to move with confidence even in cramped spaces.

The articulated chassis and equal sized wheels ensure agile manoeuvring when used indoors or in building yards. Whatever gap the front half-frame goes through, the rear half- frame will follow.

The rear wheels always follow the same path of the front ones, minimising compaction of the ground. Its articulated steering means Turboloader can work even on the most delicate surfaces without damage, making it ideal for ideal for landscaping and maintenance of green.

VISIBILITY

Unlike a traditional articulated loader, Turboloader’s operator position is located in the machine’s front half-frame. Even when steering the machine, the operator always has a perfect view of the way ahead, the implement and the task being performed.

The elevated driving position offers excellent visibility, enhanced safety and superb comfort as well as improving control of the machine and it’s implements.

The side-mounted dashboard panel and the layout of the lifting boom rams also assist in providing an uncluttered view of the attachment.

TELESCOPIC BOOM

The telescopic boom of the Turboloader, standard on the M and H models, optional on the S models, allows significant lifting heights and horizontal reach. With hydraulic parallelogram as standard (optional on S models), the handling of loads is faster, simpler and safer: The self-levelling feature significantly reduces the amount of manual adjustments and loads are lifted in total safety. By selecting the floating arm position, the implements will follow irregular surfaces smoothly and with ease. The simultaneous movement of the arm and bucket helps reduce cycle times and enhance productivity.

QUICK CONNECT

Replacing the attachments is very quick and only takes a few seconds due to the quick connect system. The implements are easily fitted and released from the operators seat by using an electronic joystick control that activates a pair of hydraulic latches. The flat-face hydraulic couplings are very easy to clean and are ideal for use in dusty or dirty environments. They prevent fluid leaks and air pockets developing in the circuit during connection and disconnection, aside from guaranteeing better performance thanks to reduced load loss.

ENGINE	Stage V – h-H 440-25
FUEL	Diesel
ENGINE HP	26 Ιπποι -19.2KW
CYLINDERS	4
WEIGHT	1710kg
HEIGHT	308mm
MAX LIFTING HEIGHT	1400
POWER	1500 Ν

TRANSMISSION

The permanent 4-wheel drive hydrostatic transmission uses high quality, robust, reliable components. The high specification of the components ensures ample pushing force together with a high transport speed, allowing for maximum productivity. Turboloader’s standard equipment includes a useful anti- slip device which can help extricate the machine in low-grip situations. As an additional aid for difficult situations a flow divider can be activated which divides the hydraulic flow (optional) and obtain a differential locking effect.

SAFETY

An FOPS protection structure against falling objects equips all models, both those with ROPS protection frame and those fitted with cab. The standard equipment of the Turboloader includes a machine anti-spill device that warns the operator in case of excessive lightening of the rear axle and, in models M and H, locks the telescopic extension of the boom. Furthermore, the M and H ranges feature an load anti-spill device that prevents the load accidentally spilling backwards on top of the operator.* with counterweights, PU filled tyres and cab.
